angle steel transmission line steel towers

Look here!China factory direct steel tower, professional manufactures,supplier and exporters for 10kV-500kV Power electric transmission tower,has own factory and production lines, with an annual product of 30000 tons, sufficient supply capacity and rich oversea export experience.CONTACT NOW!


  • Product name: 33kV Transmission Line Lattice Steel Tower
  • Material: Steel Q355B/Q255B
  • Application: Electric Power Transmission line
  • Certificate: ISO9001:2008
  • Welding Standard: AWS D 1.1
  • Surface Treatment: Hot Dipped Galvanized
  • Galvanization Standard: ASTM A123
  • Product Detail

    Product Tags

    angle steel transmission line steel towers,
    132kv line, Double Circuit Tower, Electric Power Transmission, Electric Transmission Lines, Galvanized Steel Pole, High Voltage Tower, Lattice Steel Tower, Power Line Tower, straight tower, Transmission Line Tower, Transmission Tower Design,

    Kinds of transmission towers

    For power transmission towers in various situations, you are welcome to come for customized consultation, professional design team and one-stop service are provided!

    angualr steel electric towers can be designed to carry either one or two electrical circuits, referred to as single-circuit and doublecircuit structures.

    A single-circuit(The first row in the image below) alternating current (AC) transmission line has three phases. At low voltages, a phase usually consists of one conductor. At high voltages (over 200 kV), a phase can consist of multiple conductors (bundled) separated by short spacers.

    A double-circuit(The second row in the image below) AC transmission line has two sets of three phases.

    4_副本

    Design Specifications

    Product name 33kV 35kV Electric Power Transmission Line Tower
    Wind speed 0-320 km/hr (3s gust)
    Foundation type Independent foundation/Raft foundation/Pile foundation
    Geological condition Soft ground/ Mountain ground/ Other
    Shape Square or as per design
    Connection type Bolts
    Design code ANSI/TIA-EIA-222-G
    Material grade Q255B/355B
    Deflection <1/1000 or as client’s requirement
    Design load As per client’s requirement
    Design life 30 years
    Quality system ISO 9001:2008


    Materials – Angle Steel



    Tower Details

    1. High Quality Material:adopt steelstructure steel,strong and stable,the product has passed many test,let you test assured

    2. Strong Vibration Resistance:made of quality material,it has excellent impact resistance and can withstand a magnitude & earthquake

    3. Rust Resistance:the transmission line angle steel tower has three and four legs, all of which are made of corrosion-resistant material

    4. Apperance is Beautiful:beautiful apperance,corrosion resistance,with good performance of conductive transmission line steel lattoice tower

    ”"


    Package

    Every piece of our products is coded according to the detail drawing. Every code will be put a steel seal on each piece. According to the code, clients will clearly know a single piece belong to which type and segments.

    All the pieces are properly numbered and packaged through the drawing which could guarantee no single piece missing and easily to be installed.

    ”1_副本”

     To get professional quotations, please email to us or submit the following sheet, we will contact you in 24 hours and pls check your emailbox.

    Warmly Welcome To Contact US!



    We provide the most professional one-stop steel tower service,specializing in power transmission line construction, telecommunication tower construction,
    substation steel structure Works.

    ⦁ All kinds of telecom tower customized design can be provided

    ⦁ Own professional design team for overseas steel towers projects



    ”1629335711(1)”Dear future partner,

    Good day!

    Thanks for giving Sichuan Xiang Yue Power Line Components Co., Ltd. the opportunity to become your supply company. We cover production, design, installation and maintenance of telecommunication tower,transmission line tower,all kinds of steel structure, light poles and stringing equipments. Top-quality with competitive-cost, professional technical support and well-developed after-sale service is what we pursue.

    We are looking forward a business connection with you, any ideas and questions are welcome.
    Await your earliest reply.

    Take care and have a great day.
